Mrežna oprema
| Model | RT-BE86U |
| Priključci | 1 x 10G for WAN/LAN 1 x 2.5G for WAN/LAN 3 x 2.5G for LAN USB 3.2 Gen1 x1 USB 2.0 Gen1 x1 |
| Protokol | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) WiFi 7 (802.11be) IPv4 IPv6 |
| Antena | Tri vanjske antene Jedna unutarnja antena |
| Mod rada | Wireless Router Mode AiMesh Node Mode Access Point Mode Media Bridge Mode Repeater Mode |
| Prijenos podataka | WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps WiFi 7 (802.11be) (5GHz): up to 5764 Mbps |
| Radna frekvencija | 2.4 GHz 5 GHz |
| Karakteristike | Procesor: 2.6GHz quad-core processor Memorija: 256 MB Flash, 1 GB RAM |
| Podešavanje i upravljanje | WEB: ASUSWRT APP: ASUS Router APP |
| Sigurnost | AiProtection VPN WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, WPA3 Enterprise, Open System i OWE WPS Lets Encrypt DNS-over-TLS SSH Security Scan Firewall • Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64 |
| Napajanje | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 5 A current ； 19.5 V with max. 2.31 A current |
| Wireless karakteristike | MU-MIMO UTF-8 SSID WiFi MAC Address Filter • Maximum MAC Filters : 64 Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming |
| Dimenzije i masa | 235 x 90 x 316 mm 854 g |
| Ostalo | Tipke: WPS Button, Reset Button, Power Switch, LED on/off Button |
| LED indikatori | WAN x1 10G Port x1 LAN x4 USB x1 2.4GHz x1 5GHz x1 Power x1 |
| VPN | Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Support Surfshark |
| WAN | Internet Connection Type : • PPPoE • PPTP • L2TP • Automatic IP • Static IP • IPSec Dual WAN WAN Aggregation 3G / 4G LTE dongle Port forwarding • Maximum Port Forwarding Rule : 64 Port triggering • Maximum Port Triggering Rule : 32 DMZ DDNS NAT Passthrough : • PPTP Pass-Through • L2TP Pass-Through • IPSec Pass-Through • RTSP Pass-Through • H.323 Pass-Through • SIP Pass-Through • PPPoE Relay |
| LAN | DHCP Server IGMP Snooping IPTV LAN Link Aggregation Manually Assign IP Address • Maximum Manually Assign IP Address Rule : 128 Wake on LAN (WOL) |
| USB | File System : • HFS+ • NTFS • vFAT • ext2 • ext3 • ext4 Safely Remove Disk AiCloud Download Master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder Privileges |
| Napomena | Više detalja o proizvodu možete pogledati ovdje. |
| Dimenzije i težina: | širina: 22 cm - duljina: 30 cm - visina: 13 cm - težina: 1,9 kg |
| Jamstvo: | 3 (godina) |
Brand: ASUS OPEN SYSTEM
Broj proizvoda proizvođača: 90IG08W0-MO9A0V
